Introducing the JOYANCE Agricultural Plant Protection Drone’s Centrifugal Nozzle

JOYANCE agricultural drones are equipped with state-of-the-art centrifugal nozzles designed for precision and efficiency in crop spraying operations. These nozzles are meticulously engineered to deliver superior performance with the following specifications:

**Specifications:**

– **Shell Material:** Aluminum Alloy
– **Nozzle Height:** 30 cm
– **Mist Particle Diameter:** 50-200 microns
– **Working Range:** Water Supply 200-2000 mL/min
– **Atomized Spray Width:** 1.5-2.0 meters
– **Voltage:** 12-14S Power Supply
– **Speed:** 20,000 rpm
– **Signal:** PWM (1000-2000)
– **Power:** 60W
– **Weight:** 260 grams
– **Length:** Total Length 300MM

**Advantages of the New Centrifugal Nozzle:**

1. **Enhanced Durability:** The nozzle is equipped with brushless motors and ESCs (Electronic Speed Controllers) that boast a longer lifespan, ensuring reliable performance over extended periods.
2. **Integrated Design:** The motor, ESC, and atomizing disc are all integrated into a single unit, streamlining the design and improving overall functionality.
3. **Improved Protection:** The dustproof and waterproof level of the nozzle has been upgraded to IP68, providing robust protection against environmental hazards.
4. **DJI-Grade Atomizing Disc:** The nozzle uses the same type of atomizing disc as DJI, offering double atomization and uniform droplets for precise application.

**Use Environment of Centrifugal Nozzle:**

1. **Dense Crops:** The nozzle is ideal for crops with dense branches and leaves, such as fruit trees, where a large amount of pesticides needs to be applied.
2. **Low-Speed Flight:** For optimal performance, the drone should operate at low speeds, ideally less than 4m/s. High-speed flights can easily cause liquid hoisting and drifting.
3. **Breeze or No Wind:** It is best used in breeze or no wind conditions, as the small and lightweight fog droplets are susceptible to wind interference.

**Advantages:**

– **Excellent Atomization:** The nozzle provides superior atomization, ensuring that the pesticides are evenly distributed and effectively cover the intended area.
– **Supports Large Flow:** The design allows for large flow rates, making it suitable for extensive spraying operations.

**Disadvantages:**

– **Susceptible to High-Speed Flights:** The nozzle is prone to hoisting at high speeds, which can compromise the spray’s accuracy.
– **Wind Sensitivity:** It is susceptible to wind, which can cause drifting and reduce the effectiveness of the spray.
– **Higher Cost:** The advanced technology and materials used in the nozzle result in a higher cost.
– **Shorter Life Span:** Despite the improved durability, the nozzle’s life span may be shorter compared to other types, especially in harsh operating conditions.

JOYANCE’s centrifugal nozzle represents a significant advancement in agricultural drone technology, providing a powerful tool for precision crop protection.
